Operators Manual Model PT2000/H Series Gas Monitor Rev 2. January 2014
4.6 Alarm Test
This function primarily used to troubleshoot or test for proper alarm relay connections.
Gas Alarm Drill
To activate alarm simply tap the button to toggle between ON and OFF. The relay
(alarm) is activated when button is ON and deactivated when OFF.
As per screen shot below, Low H2S Alarm and High H2S Alarm Device should be
active, (Amber Strobe and Horn as per logic in the previous section)
Upon Exit all alarm relays will be deactivated.
