13. Technical data/ Maintenance 14. Imprint
Responsible for content and illustrations
Pendix GmbH
Innere Schneeberger Straße 20
08056 Zwickau
Germany
Telephone: +49 (0) 375 270 667 10
email: info@pendix.de
These operating instructions are covered by requirements
and scope of EN ISO (European Norm, International Stand-
ards Organization) 4210:2014 and 15194:2017.
When supply and eective use are outside the range of these
instructions, the relevant instructions by the manufacturer
of the bicycle used must be included.
© reproduction, copying and translation
including any other active commercial use (also in the form
of excepts and/or in printed or electronic Form) are only per-
missible aer previous agreement to same in written form.
Pendix EN, 11.21 Rev.03, A3D.705.003
Pendix GmbH
Innere Schneeberger Straße 20
08056 Zwickau
www.pendix.de
Germany
In service cases please contact your contracting
partner.
eMachine
Motor
gearless
mid-mounted motor
Performance 250 W nominal
Speed (max) 25 km/h
Assistance levels 3
Torque (max) 65 Nm
Sound pressure level
Lpmax in dB(A)
passing through with
motor
45.1
Starting with motor 49.0
ePower500 (battery)
Type Lithium-Ionen 13S3P
Capacity 497 Wh nominal
Voltage (norm) 48 V
Distance* 62 - 120 km
Overall system
System weight 6.9 kg (eDrive300)
7.3 kg (eDrive500)
Operating temperature -10° C to +50° C
Storage temperature -20° C to +60° C
Tightening torque values for screw connections
Battery holder on the
frame (with safety screws)
4.5 Nm ± 0.5 Nm
Right-hand assembly side
(greased)
15 Nm
± 2 Nm
Bottom bracket mounting
(greased)
65 Nm
± 3 Nm
Crank screw le/right (with
safety screws and grease
on square sha)
32 Nm
± 2 Nm
Pedal le/right 35 Nm
± 2 Nm
Connector cover to battery
holder
2.4 Nm
± 0.2 Nm
Chain wheel screws, steel 9 Nm
± 2 Nm
ePower300 (battery)
Type Lithium-Ionen 13S2P
Capacity 300 Wh nominal
Voltage (norm) 48 V
Distance* 37 - 72 km
Dimensions (width x height x depth)
ePower300 (battery) 80 x 276 mm
ePower500 (battery) 80 x 342 mm
eMachine 292 x 206 x 50 mm
*the generated riding profile "performance" (factory set-
tings) data is depending on parameters as total weight, driv-
ing behavior, topography, pedaling cadence and bike type
The built-in electronic bottom bracket is a me-
chanical wearing part. The durability is specified
with 20,000km, aer which the bottom bracket
should be replaced.
