4. Scope of supply
Pos.-
no.
Description Article no. eDrive300 eDrive500 eDrive1000
1 Drive system unit; 250 W
preassembled: coupling ring
A3C.902.140
A1C.301.002
1
2 Crank; 172.5 mm A1C.302.001 1
3 Battery ePower300; 48 V; 13S2P B1C.904.071 1 - -
4 Battery ePower500; 48 V; 13S3P B2C.904.071 - 1 2
5 Battery holder A1C.904.022 1
- Screws battery holder
• Screws battery holder M5x16
• Screws for connector cover M4x16
self-cutting
A1C.402.205
A1C.402.211
1
6
Charging unit HG Power; 160 W; 54.6 V; 3 A
B5C.904.081 1 1 1
7 Charging unit HG Power; 60 W; 54.6 V; 1.1 A B4C.904.081 - - 1
8 Bottom bracket unit composed of:
• Bottom bracket
• Bottom bracket mounting
• 2 spacer rings
• Wave washer
• 2 crank screws
• Screwed bushing aluminium
A1C.903.030
A1C.301.034
A1C.301.003
A1C.301.221
A1C.301.202
A1C.301.031
1
9 Assembly set wheel speed sensor
• Wheel speed sensor 290 mm / 580 mm
• Spoke magnet
A1C.903.070.0 / -070.1
A1C.301.207
1
- Installation/System instructions A3D.705.003/
A3D.705.002
1
On the following page you will find a general overview of the components on the bike.
3.1 Residual risks
Observe compliance with the permissible total
weight aer installation of the Pendix eDrive in
the bicycle:
Total weight = Pedelec weight + rider weight +
load weight
This total weight must not exceed the permissi-
ble total weight originally specified by the bicycle
manufacturer.
Incorrect mounting of the drive can cause seri-
ous damage. Please check the tight fit of the mo-
tor on the bottom bracket as well as the battery
holder and battery before each ride.
Installation of the Pendix eDrive may result in
slightly increased wear of chain rings, sprockets
and chain/belt. Please observe the maintenance
intervals for checking/replacing these compo-
nents in the Pedelec manual.
