10. Installation check list
Before installation: inspection of safety-relevant components on the bicycle
If there are former damages on safety-relevant components identifiable that do not allow a safe operation, please desist from installing the Pendix eDrive as long as
the deficiency on the aected components is not remedied. check
check
brakes (at least two brakes existing, functionality, wear)
fork (age, visible damage, deformation)
frame (age, visible damage, deformation)
handlebar (age, visible damage, deformation)
tires (flaws, wear)
rims (visible damage, deformation)
Before installation: Checking the requirements for Pendix installation done check check
bottom bracket BSA thread / bottom bracket width 68 mm or 73 mm
bottle mounts existing → if not: using Pendix clamp mounts
installation space for battery & battery holder (down tube trapeze frame)
chainwheel(s) with correct fitting dimension for crank (Ø104/ 64 mm bolt circle)
frame material metallic? No → consultation with Pendix service
cable length needed from motor through battery holder 250 mm/ 500 mm
cable length needed from wheel speed sensor through motor 290 mm/ 580 mm
During the installation: all installation works have to be done without battery inserted! check
wheel speed sensor mounted and wires placed according to installation manual
spoke magnet positioned and mounted according to installation manual
bottom bracket thread greased
spacers on bottom bracket according to installation manual at
68 mm housing width: used!
73 mm housing width: not used!
In order to minimize the risk of liability for commercial fitters, we recommend the documentation of the installation using the “installation report” function, which is integrated
in the Pendix.bike PRO App!
