9
EasyTouch Control System User’s Guide
Quick Start - Spa and Pool Operations (Shared Equipment)
The following describes how to adjust heat temperature for the spa and pool water, schedule a daily run time
for the pool/spa filter pump and control lights for shared equipment.
Heat your spa or pool
First enable the heat source (see “Adjust your spa heat settings” below) then press
the Valves (V) button to enable “Spa” mode, and press the Filter Pump button to
activate the filter pump. When in normal operating mode, the Valves (V) button is in
“Pool” mode which turns valves and activates the filter pump automatically so that
only the pool water is circulated through the system. Press the button to enable “Spa”
mode and activate the Filter pump to circulate only spa water through the system. In
the main screen shown on left, 95°F (35°) is the current temperature and 100° F
(38° C) is set point temperature. By default, the setting “Man Heat’ is set to “On”
(see page 52) which allows the spa to begin to heat whenever it is manually switched
on.
From the Indoor or wireless control panel (option): First enable the heat source
in the Heat menu (see “Heat Menu,” on page 25). Press the Spa button (top button)
to switch the filter pump on, rotate the valve actuator (to isolate spa water from pool
water), and switch the heater on. Press the Pool button to switch the filter pump on,
rotate the valve actuator (to isolate pool water from spa water), and switch the heater
on. For Pool and Spa button location, see page 7.
Adjust your spa or pool heat settings
From the “Heat” menu (MENU > HEAT > POOL TEMP/SRC OR SPA TEMP/SCR) you can select the heat
source and set the water temperature. The spa or pool water will heat to the settings specified. The
EasyTouch system allows for solar and conventional heaters. The EasyTouch will use the heating source that
is selected. The heat source selections are:
•
OFF - No heating even though pump and other circuits may be operating.
• HEATER - Gas heater only.
• SOLAR - Solar heating system to be the only heat source. In order to display “Solar Only” as a heat
option in the “Heat” menu, you must first enable solar in the Settings > Solar menu,
(see page 47).
• SOLAR PREF. (Solar Preferred) - Used if solar and gas heating are combined and you want to use
solar heating only when it is most effective. In order to display “Solar Preferred” as a heat option in
the “Heat” menu, you must first enable solar in the Settings > Solar menu.
• Heat Pump (UltraTemp): If a heat pump is being used (UltraTemp), enable the UltraTemp and heating
setting from the SETTINGS > HEAT PUMP COM > SETTINGS menu options (see page 41).
To set the spa temperature set point and select the heat source:
Right button: Select spa temperature and heat source.
Up/Down button: Adjust the spa water temperature from 40° F to 104° F
(4° C to 40° C)
Right or Left button: Move to Heat source options.
Up/Down: Set the Heat option: Off, Heater, Solar, or Solar Preferred.
Press the Menu button to save the settings and to return to the Heat menu or press
the button again to return to the main screen. Note: Select “
POOL Temp/Src” to
adjust the pool temperature.
AUTO HEATER
SPA 95°F / 100°F
AIR 70°F
MON 09:30 AM
POOL Temp/Src
SPA Temp/Src
X
T
S
SPA
Set Temp: 85° F
Heat: Heater
T
S
Getting There
MENU HEAT
▲
