31
EasyTouch Control System User’s Guide
Settings Menu: Clock
Use the Clock menu to set the EasyTouch system date and time. The day, time and AM/PM is displayed on
the main screen. The system clock settings are used for the EasyTouch system scheduled operations. The
EasyTouch system clock will continue to run if power is removed from the EasyTouch system at the load
center.
Clock
To set the system date and time:
Right button: Move to the day setting.
Up/Down buttons: Set the day of the month.
Right button: Move to the year setting.
Up/Down buttons: Set the year.
Right button: Move to the next set of settings (2/2).
Up/Down buttons: Set Daylight Savings to Auto or Manual. Auto keep track of the
semi annual time changes. If you do not live in an area that observes daylight savings
time, choose Manual.
Right button: Move to the clock adjustment setting. If the internal system clock
loses time during the month, use this setting to set the number of seconds in five
second increments per month to automatically adjust the clock to the correct time.
Up/Down buttons: Adjust the offset in five second increments.
Press the Menu button to save the settings and to return to the Settings menu
options. Press the button again to return to the main menu options or press again to
return to the main screen.
Getting There
MENU ▼ SETTINGS CLOCK
▲
Date & Time 1/2
JAN 12 2009
09:20 AM
T
S
Date & Time 2/2
DayLt Sav: Auto
Clk Adj: 00:00
T
S
Settings Menu: IntelliFlo
®
(and IntelliPro
®
pump)
The EasyTouch system communicates with the IntelliFlo pump via a two-wire RS-485 cable (PN 350122).
IntelliFlo operations can be controlled from the EasyTouch indoor and outdoor control panel and the EasyTouch
wireless remote. EasyTouch supports the following pumps: IntelliFlo VF3050 (15-130 GPM), IntelliPro
VF3050 (15-130 GPM), IntelliFlo VS+SVRS (1100-3450 RPM), IntelliFlo VS3050 (400-3110 RPM),
IntelliPro VS3050 (400-3450 RPM) and IntelliFlo VSF+SVRS. For more information refer to the following
manuals: IntelliFlo VF 3050 (P/N 350075), IntelliFlo VS 3050 (P/N 357269), IntelliFlo VSF+SVRS (P/N
351420).
How many IntelliFlo pumps will EasyTouch support?
EasyTouch can support a total of two IntelliFlo (or IntelliPro) VF3050 or IntelliFlo VS3050 (or VSF+SVRS) pumps
in any combination with up to eight GPMs or RPMs per pump. For example pumps can be connected to
EasyTouch as follows:
•1 IntelliFlo VF + 1 IntelliFlo VS (or VSF+SVRS)
•2 IntelliFlo VF
•2 IntelliFlo VS (or VSF+SVRS)
Note: IntelliFlo pumps cannot be connected in series with other pumps. Check valves must be used when a
pump is used in parallel with other pumps.
To Next Page
