17
P15003 (12-15-22)
KEY NO PART DESCRIPTION QTY
FP4155 FP4157-01 FP4150
1/2 HP 3/4 HP 1 HP
1 Motor and Seal Plate Assembly 1
See Kits Below
1A Motor Flange Screw 4
2 Seal Plate O-Ring 1
3 Pressure Switch 1
4 Shaft Seal 1
5 Impeller 1
6 1/4" NPT x 1/4" Barbed Elbow 2
7 Hose 1
8 Diffuser 1
9 Diffuser Plate 1
10 Diffuser Plate O-Ring 1
11 Diffuser Plate Washer 3
12 Diffuser Plate Screw 3
13 Venturi 1
14 Nozzle 1
15 Pump Body 1
Seal Kit (Includes 2, 4, 10)
1
RPK-35 RPK-35 RPK-35
Overhaul Kit (Includes 1A, 2, 4, 5, 8, 9, 10, 11 (3), 12 (3), 13, 14)
1 RPK-205DW RPK-207DW RPK-210DW
Pump Body Assembly (Includes 2, 6, 13, 14, 15, 1/4" NPT Plug (2), 1/2" NPT Plug)
1
R176-72 R176-72 R176-72
Ejector Kit (Includes 6(2), 7, 13(5), 14(2), 16, 17, 18(2), 19(2)
1 FP520-100 FP520-100 FP520-100
Pressure Regulator
1
FPAPR FPAPR FPAPR
Pressure Switch
1
TC2151 TC2151 TC2151
Pressure Switch Tubing Kit (Includes 6(3), 7)
1
FPASFK FPASFK FPASFK
FLOTEC MODELS
PARTS INDEX
