Pentair intellidrive pid10 User Manual

Table 5 - Continued
Menu
Settings
Parameter
Unit of
Measure
Value
Description
Default Min Max
Setpoints
Internal
Setpoint
PSI 60 PSI 15 PSI
Max
Sensor
Value
minus 3
PSI.
Mainpressuresetpointused.Sets
main system operational pressure.
This parameter is accessed here,
through PSI Preset button, or by
pressing Enter button while in
Constant Pressure operation.
External
Setpoint
PSI 40 PSI 15 PSI
Max
Sensor
Value
minus 3
PSI.
Second pressure setpoint. When
another pressure setting is desired
other than Internal Setpoint.
Additional programming needed in
I/O section. Requires an external
switch or timer to be wired to
digital input terminals. It is only
active when there is voltage present
at the digital inputterminals.
Sub Menu Parameter
Unit of
Measure
Default Min Max Description
Motor
Motor Phase _ 1 1 3
Selects phase of motor to be
operated. An additional sub menu
will appear, based on phase
selection, to select proper motor
type.
Connection
Type
– 3 wire 3 wire 2 wire
Wire type for 1 phase motor
operation only. Can only access by
firstsettingMotorPhaseparameter
to 1 Phase.
Motor Type – Subm Subm
Above
Gnd
Motortypefor3phasemotor
operation only. Can only access by
first setting Motor Phase parameter
to 3 Phase.
Service Factor
Amps
A 00.0 A 00.0 A
Per
drive
and
motor
Service factor amps (max. load) of
motor the Drive is operating. Sets
maximum allowed amps at output
of Drive. See Table 8 for values.
Min Frequency Hz 30 Hz 30 Hz
1 below
Max
Hz
Minimumfrequency(speed)motor
will run.
Max
Frequency
Hz 60 Hz
1 above
Min
Hz
80 Hz
Maximumfrequency(speed)
motor will run. Up to 80Hz is only
available on submersible 3-phase
motors (when motor is 2x the HP
of pump).
Sensor
Max Sensor
Value
PSI 100 PSI 100 PSI 300 PSI
Maximumpressurevalueof
transducer sensor used with Drive.
Only change if different transducer
is used with Drive, other than 100
PSI max scale.
Programming 14
