Features – Flow Duration/Rate/Start–Stop Time
Features 3 – 9 Features 3 through 9 enable you to assign additional water features for timed
operation. These features are fully controlled by IntelliFlo
®
VF Variable Flow
Pump’s internal clock. You will need to program a flow rate and start/stop time for
each feature.
Note: Feature 3 through 9 program times cannot overlap.
When a feature is running, the pump will monitor GPM and subtract time from the
filter cycle. All sensors are active during any Feature 3 – 9 cycle.
Enabling Features 3 – 9 Features must be enabled before they will operate.
To enable, press , and to save the setting.
Setting Flow Rate Flow Rate for Features 3 – 9
Press to access Set Flow. Press to access the Flow setting.
Press and to select digit to modify. Change values by pressing and
When value is set, press to confirm value and save changes.
Setting Start/Stop Times for Features 3 – 9
Press to select Start Time or Stop Time Setting. Press to access the
setting.
Press and to select digit to modify. Change values by pressing and
When value is set, press to confirm value and save changes.
Enter
Enter
Enter
15
IntelliFlo
®
VF Pump Quick-Start Guide
