Pentair IntelliFlo VF Quick Start Guide

Stand Alone Set-Up
Manual Mode Stand-Alone Set-Up
(no controller or appliance communicating with the IntelliFlo
®
VF Variable Flow Pump)
Manual Mode is used for first-time programming, service and testing, or when
ever you need to quickly measure or set flow rates for equipment and features.
(Please refer to page 9 of the IntelliFlo VF Variable Flow Pump Installation and
User’s Guide.)
Note: Before initial IntelliFlo VF pump programming,
set system valves for your pool circulation mode.
Pool Data Mode Setting Pool Parameters in Pool Data mode
Pool Data mode is used to give the pump information about pool volume and
water temperature. You also set the time clock, adjust screen contrast, and
program the pump address (if needed for IntelliTouch
®
Control System) in Pool
Data mode.
Press to access Pool Data. Press to set parameters.
Pump Address
Only used when linked to control system – See IntelliFlo
VF Pump Installation
and User’s Guide for installation with Pentair automated control systems. Skip to
Pool Volume if stand alone installation.
7
IntelliFlo
®
VF Pump Quick-Start Guide
