Pentair IntelliFlo VF Quick Start Guide

Filter/LED – Starts Filter mode.
The LED is on when Filter mode is active.
Vacuum/LED – Starts Vacuum mode.
The LED is on when Vacuum mode is active.
Backwash/LED – Starts Backwash mode.
The LED is on when Backwash mode is active.
Manual/LED – Starts Manual mode. The LED is
on when Manual mode is active.
Select – Displays menu items or enters edit mode
for changing a value on line two of display.
Escape – Go up to next menu level, or stop
editing the current setting.
Menu – Access menus if pump is stopped.
Enter – Saves current menu item setting,
acknowledges and clears alarms and warnings.
Arrows
Up – Move one level up in the menu tree or
increase a digit when editing a setting.
Down – Move one level down in the menu tree or
decrease a digit when editing a setting.
Left – Move cursor left one digit when editing a
setting.
Right – Move cursor right one digit when editing a
setting.
Feature 1 – Starts Feature 1 mode.
The LED is lit when mode is active.
Feature 2 – Starts Feature 2 mode.
The LED is lit when mode is active.
Start/Stop – Start or Stop the pump. When the
LED is lit it indicates the pump is currently
running or in a mode to start automatically.
Reset – Reset alarm or alert.
LEDs
On – This green LED is on when pump is
powered on.
Warning – This LED is on if a warning
condition is present.
Alarm – This LED is on if an alarm condition
has occurred.
Control Panel LCD Display
Line 1 – Mode and time.
Line 2 – Data.
Line 3 – Name of data in line 2.
Line 4 – Run status.
Operator Control Panel
1
2
3
4
5
6
7
8
9
10
11
13
12
14
15
5
IntelliFlo
®
VF Pump Quick-Start Guide
