29
No. Part No. Description Spare Part used in
E - 08 E - 10 E - 12 E - 15
1 474861 Water Flow Switch √ √ √ √
2
474863
Compressor**
√
474864 Compressor** √
474865
Compressor**
√
474866 Compressor** √
*
474862
Compressor Cable
√
√
3 474871 Refrigerant Accumulator** √
4
474873
Fan Motor (incl. Nut & Washer)
√
√
474874 Fan Motor (incl. Nut & Washer) √ √
5 474877 Fan Blade √ √
474878 Fan Blade √ √
* 474879 Evaporator plastic grill √ √
* 474880 Evaporator plastic grill √ √
6 474881 4-way Valve (Mechanical)** √ √
474882 4-way Valve (Mechanical)** √
474883 4-way Valve (Mechanical)** √
* 474884 4-way Valve (Solenoid) √ √ √ √
7 474885 Cable Glands (PG16) √ √
474886 Cable Glands (PG20) √ √
*
474887
Complete R410a Schra
der valve**
√
√
√
√
8 474888 Fan grill (incl.screws, washers & nuts) √ √
474889
Fan grill (incl.screws, washers & nuts)
√
√
9 474890 Gas pressure gauge (incl.support)** √ √ √ √
10
474854
Digital Controller
√
√
√
√
11 474891 Condensor Kit** √
474892
Condensor Kit**
√
474893 Condensor Kit** √
474894
Condensor Kit**
√
* 474895 Accessory bag (water IN/OUT conn. + 4x silentblocs) √ √ √ √
13 474896 Front Panel √ √
474897 Front Panel √ √
14 474898 Top Panel √ √
474899 Top Panel √ √
15 474900 Back Panel √ √
474901 Back Panel √
474902 Back Panel √
16
474903
Right Panel
√
√
474904 Right Panel √ √
17
474905
Left Panel
√
√
474906 Left Panel √ √
18
473665
Water Temperature Sensor
√
√
√
√
19 473665 Defrost Temperature Sensor √ √ √ √
20
474850
Terminal Blocks (power supply) + wire harness
√
√
√
√
21 474851 Terminal Blocks (input/output conn.) + wire harness √ √ √ √
22
474852
Terminal Blocks (24V) + wire harness
√
√
√
√
23 474853 Transformer 230V/24V √ √ √ √
24
474855
24V Relay (inc
l.socket)
√
√
√
√
25 474856 Compressor contactor (18A) √ √
474857
Compressor contactor (25A)
√
474858 Compressor contactor (32A) √
*
474859
High Pressure switch**
√
√
√
√
474860 Low Pressure switch** √ √ √ √
26
474872
Soft Starter
√
27 474875 Fan Motor Capacitor √ √
474876
Fan Motor Capacitor
√
√
28 474867 Compressor Capacitor √ √
474868
Compressor Capacitor
√
474869 Compressor Capacitor √
29
474870
Soft Started Capacitor
√
* 474907 Screw Set √ √ √ √
*
474908
Winterizing Cover
√
√
474909 Winterizing Cover √ √
* Not Shown
** replacing this component requires changing the refrigerant
