Pentax MZ-S Service Manual

27640 -7/34-
8). Back cover SW
8). Back cover SW8). Back cover SW
8). Back cover SW·
··
· Winding
Winding Winding
Winding·
··
· Rewinding
Rewinding Rewinding
Rewinding
-1）The film should be wound and exposure counter advances to [1] when loading 36ex.
test film, close the back cover and turn the main SW on.
-2）Release shutter several times and check to see the advancing film，the film counter
advances properly.
When the film is advances 30 exposures, Film mark should brink and PCV should
start ringing.
-3）Check to see that the film should be rewound when depressing mid - roll rewind button.
-4）There should not exist any abnormal sound or noise when winding and rewinding film.
9). Flash discharging
9). Flash discharging 9). Flash discharging
9). Flash discharging ·
··
· Mode switching.
Mode switching. Mode switching.
Mode switching.
-1）Flash mark should indicate when the flash is popped-up.
-2）Flash mode should change when turning Tv dial while depressing side button.
-3）Check the function of Red eye reduction mode・A Auto discharge mode.
10). AF check(Attach FA lens and set at AF.S mode. )
10). AF check(Attach FA lens and set at AF.S mode. )10). AF check(Attach FA lens and set at AF.S mode. )
10). AF check(Attach FA lens and set at AF.S mode. )
-1）When depressing AF button while lens front cover is covered with fingers,
the distance ring should move from closest distance to infinity ().
-2）Assistance spot beam (continuous light) should work when depressing AF button
with lens front cap on and flash is popped-up.
-3）When turning Tv dial while pushing AF area mode lever to SEL, AF area switches
securely.
-4）AF area(point) should be fixed when the AF area mode lever is set to L.
6 divided AF area mode should work properly when mode lever switches A.
11). Lens mount index lamp.
11). Lens mount index lamp.11). Lens mount index lamp.
11). Lens mount index lamp.
Lens mount index lamp turns on when depressing mount lock button without lens
attached.
(It should be checked out in darker space.)
