27640 -28/34-
[
[[
[27640
2764027640
27640 PROGRAM
PROGRAM PROGRAM
PROGRAMＭＥＤ
ＭＥＤＭＥＤ
ＭＥＤ SOFTWARE FLOW CHART]
SOFTWARE FLOW CHART] SOFTWARE FLOW CHART]
SOFTWARE FLOW CHART]
[ 1 ] [ 2 ]
[ N ] [ Y ]
[ 1 ] EEPROM CHECKING (START) [ 5 ] EEPROM CHECKING (END)
***** 27640 TEST PROGRAM *****
TURN MAIN SW OF BODY ON.
TURN SW OF I/O IF BOX ON.
AFTER CONFIRMING ABOVE, PRESS KEY [ 1 ].
AFTER REPLACING MAIN PC BOARD, PRESS KEY [ 2 ].
BATTERY LEVEL ADJUSTMENT ( ---> [ 6 ] )
AFTER REPLACING SHUTTER BLOCK [ Y / N ]
***** 27640 MAIN MENU *****
EEPROM CHECKING (START) ---> [ 1 ]
EXPOSURE ADJUSTMENTS (A) ---> [ 2 ]
AF AND RELATED ADJUSTMENTS (B) ---> [ 3 ]
NUMBER OF REPAIRS ---> [ 4 ]
EEPROM CHECKING (END) ---> [ 5 ]
BATTERY LEVEL ADJUSTMENT ---> [ 6 ]
SHUTTER SPEED ADJUSTMENT ---> [ 7 ]
FOCUS INDICATION CHECKING ---> [ 8 ]
***** EEPROM CHECKING (START) *****
IF YOU ARE READY TO START, PRESS KEY [ Y ].
HEN YOU RETURN TO MAIN MENU, PRESS KEY [ N ].
BEING REPAIRED.
DATA OF EEPROM IS BEING CHECKED.
DATA OF EEPROM IS ALL OK!!
EEPROM DATA CHECKING HAS BEEN COMPLETE
EEPROM CHECKING AGAIN ---> [ 1 ]
MAIN MENU ---> [ 2 ]
***** EEPROM CHECKING (END) *****
IF YOU ARE READY TO START, PRESS KEY [ Y ].
HEN YOU RETURN TO MAIN MENU, PRESS KEY [ N ].
BEING REPAIRED.
DATA OF EEPROM IS BEING CHECKED.
DATA OF EEPROM IS ALL OK!!
EEPROM DATA CHECKING HAS BEEN COMPLETE
EEPROM CHECKING AGAIN ---> [ 1 ]
MAIN MENU ---> [ 2 ]
SHUTTER SPEED ADJUSTMENT ( ---> [ 7 ] )
