27640 -34/34-
LIST OF JIGS
・
TOOLS
・
TESTERS.
◎
◎◎
◎
Exclusive use for 27640
Exclusive use for 27640Exclusive use for 27640
Exclusive use for 27640
1.Programmed soft for 27640
PC/AT Compatible for 3.5 inches 95901 P274
2. AF adjusting jig for 27640 (Square) 95901 M519
3. AF adjusting jig for 27640 (Cross-S) 95901 M520
4. Mirror adjusting jig for 27640（MAAJ-2764） 95901 J132
5. AF chart for 27640 2m.(Attached with Service Manual/ 2m Focus Master Lens)
6. Power adapter for 27640.(Hand maid : Battery grip BG-10,solder power cord onto the
Battery contact pieces. / Battery switching dial is set at Li.)
7. Temporarily bottom cover. 95901 N56
◎
◎◎
◎
Others
OthersOthers
Others
1. AF adjusting jig for 27250(Cross) 95901 M514
2. Camera connecting cable for 27250 95901 M515
3. 2m Focus master lens(ML-259) 95901 N24
4. Back cover for TTL adjustment《Hand made》
(Exp. : Adhere LX newer 1
st
shutter curtain at the position of aperture on A221)
5. Resistance (1k ~ 2.5k, to check for positioning LED indication)
◎
◎◎
◎ Others tools and jigs are same as MZ
Others tools and jigs are same as MZOthers tools and jigs are same as MZ
Others tools and jigs are same as MZ-
--
-5
5 5
5
except Power SW adaptor
except Power SW adaptorexcept Power SW adaptor
except Power SW adaptor
(
((
(95901
95901 95901
95901 M123).
M123).M123).
M123).
1. Personal computer
2. Color display
3. Serial interface(SIFI-269), Buffer for serial
interface(IFB-269) or Camera multi Adaptor. 95901 M127
4. Hexagonal driver 1.5ｍｍ (HD-M1.5) 95901 K72
5. Shutter tester(Shutter speed or
Exposure value, should be able to measure 1/6000ms)
6. 3 lines collimator chart(OCRC-25 9) 95901 M21
7. AE master lens (ML-245) 95901 N28
8. Diaphragm set ring(F8)(KA-00-1A) 95901 N26
9. Focus master lens for 35mm.(KML-01) 95901 N17
10. AE master lens for LX(LML-240) 95901 N27
11. Dial comparator(PH-2) 95901 N1
12. Block gauge for 35mm(229N-A01-A2) 95901 N4
13. Mount block(1620-A), Substitution of
23600N-A01 Mount block/ spacer. 95901 N47
14. Mount block spacer(23600N-A01,A104-A-A) 95901 N6
15. Mount spacer holder(23600N-A01,A104-A-B)95901 N7
16. 1000mm Collimator
17. Optical regulator for MEF
18. Mirror positioning scope 95901 N49
19. 1
st
Mirror angle(45°)
adjusting jig(24000N-B2-A) 95901 J104
20. Pen light( Similar one, for adjusting position of light receiving sensor)
21. Regulated direct current power supply.
22. Circuit tester.
[Note]
[Note][Note]
[Note]
When modifying(cutting) bottom cover by yourself, Please be careful
for not to fire. Powders of Magnesium is very high flammable.
To Next Page
