Pentax MZ-S Service Manual

27640 -33/34-
***** MAIN MENU *****
[ 4 ]NUMBER OF REPAIRS [ 6 ] SHUTTER SPEED ADJUSTMEN
[ 6 ]
[ 6 ]BATTERY LEVEL ADJUSTMENTT FOCUS INDICATION CHECKING
***** NUMBER OF REPAIRS *****
NUMBER OF REPAIRS = 0 - - - > 1
IF YOU ARE READY TO START, PRESS KEY [ Y ].
WHEN YOU RETURN TO FRONT MENU, PRESS KEY [ N ].
NEXT OF EEPROM CHECKING (END) ---> [ 1 ]
***** BATTERY LEVEL ADJUSTMENT *****
SET REGULATED DC POWER SUPPLY TO 6 v.
AFTER CONFIRMING ABOVE, PRESS KEY [ Y ].
WHEN YOU RETURN TO FRONT MENU, PRESS KEY [ N ].
***** BATTERY LEVEL ADJUSTMENT *****
* SET REGULATED DC POWER SUPPLY TO 4.40 v.
( MORE THAN 3 AMPERE )
AFTER CONFIRMING ABOVE, PRESS KEY [ Y ].
WHEN YOU RETURN TO FRONT MENU, PRESS KEY [ N ].
***** SHUTTER SPEED ADJUSTMENT *****
* SET DRIVE MODE SAW OF CAMERA
TO CONSECUTIVE-FRAME MODE.
SHUTTER TESTER FOR 1/6000 SEC. ---> [ 1 ]
SHUTTER TESTER (MODEL EF-5000) ---> [ 2 ]
MAIN MENU ---> [ 3 ]
1) SET CAMERA ONTO SHUTTER TESTER.
2) OPEN BACK COVER OF CAMERA.
3) DEPRESS BACK COVER KEY.
4) SET SHUTTER DIAL TO 6000
5) SET FOCUS MODE SW TO MF.
RELEASE SHUTTER SEVERAL TIMES.
READ SHUTTER SPEED.
AFTER CONFIRMING ABOVE, PRESS KEY [ Y ].
WHEN YOU RETURN TO FRONT MENU, PRESS KEY [ N ].
***** FI CHECKING *****
* MOUNT THE FOCUS MASTER LENS ONTO CAMERA.
AFTER CONFIRMING ABOVE, PRESS KEY [ Y ].
WHEN YOU RETURN TO FRONT MENU, PRESS KEY [ N ].
***** FI CHECKING *****
NOW, ALL AF SENSORS ARE OPERTING.
* DO NOT REMOVE THE LENS FROM CAMERA.
COMBINATION OF FI CHECKING;
1) USE VERTIVAL CHART WHEN CHECKING AF FRAME.
2) USE HORIZONTAL CHART WHEN CHECKING
RIGHT & LEFT TRAME.
UNDER ABOVE CONDITION, CHECK FOCUS INDICATION.
WHEN YOU RETURN TO FRONT MENU, PRESS KEY [ Y ].
INPUT SHUTTER SPEED READING (1/6000)
DATA = ? (mS)
(WHEN YOU RETURN TO FRONT MENU,
[ N ] & RETURN/ENTER KEY.)
DO SHUTTER SPEED ADJUSTMENT AGAIN.
