27640 -29/34-
***** MAIN MENU *****
[Note]: Select 1 or 2 for your light source.
***** SELECT AE TYPE *****
TYPE 1 ( LV6,8,10,12,16 ) ---- [ 1 ]
TYPE 2 ( LV6,9,12,15 ) ---- [ 2 ]
***** AV AND BV ADJUSTMENTS *****
MOUNT F-8 SET RING ONTO CAMERA.
ATTACH LIGHT MEASURING MASTER LENS
FOR LX WITH WIDE OPENED POSITION.
SET LIGHT SOURCE TO LV 6.
AFTER CONFIRMING ABOVE, PRESS KEY [ Y ].
WHEN YOU RETURN TO FRONT MENU, PRESS KEY [ N ].
***** 27640 < A GROUP > *****
AV AND BV ADJUSTMENTS ---> [ 1 ]
TTL FLASH QUENCH SIGNAL ADJUSTMENT ---> [ 2 ]
MAIN MENU ---> [ 3 ]
SET LIGHT SOURCE TO LV 16 (or 15).
AFTER CONFIRMING ABOVE, PRESS KEY [ Y ].
WHEN YOU RETURN TO FRONT MENU, PRESS KEY [ N ].
***** TTL QUENCH SIGNAL ADJUSTMENT *****
MOUNT F-8 SET RING ONTO CAMERA.
ATTACH LIGHT MEASURING MASTER LENS
FOR LX WITH WIDE OPENED POSITION.
SET LIGHT SOURCE TO LV 8 (or 9).
ATTACH TTL ADJUSTING BACK COVER ONTO CAMERA.
AFTER CONFIRMING ABOVE, PRESS KEY [ Y ].
WHEN YOU RETURN TO FRONT MENU, PRESS KEY [ N ].
TTL QUENCH SIGNAL ADJUSTMENT HAS BEEN COMPLETED.
TTL QUENCH SIGNAL ADJUSTMENT AGAIN ---> [ 1 ]
A GROUP MENU ---> [ 2 ]
B GROUP MENU ---> [ 3 ]
AV AND BV ADJUSTMENTS HAVE BEEN COMPLETED.
AV AND BV ADJUSTMENTS AGAIN ---> [ 1 ]
NEXT OF TTL FLASH QUENCH SIGNAL ADJUSTMENT---> [ 2 ]
A GROUP MENU ---> [ 3 ]
[ 2 ] EXPOSURE ADJUSTMENTS
