Pentax MZ-S Service Manual

27640 -30/34-
***** MAIN MENU *****
[ 1 ] CCD POSITION SQUARE ADJUSTMENTS [ 2 ] CCD POSITION CROSS(L) ADJUSTMENTS [ 3 ] _CROSS(S) CHECK
***** CCD POSITION SQUARE ADJUSTMENTS *****
MOUNT CCD ADJUSTING TUBE (SQUARE) ONTO CAMERA.
SET LIGHT SOURCE TO LV 12.
SET FOCUS-MODE SAW OF CAMERA TO MF.
AFTER CONFIRMING ABOVE, PRESS KEY [ Y ].
WHEN YOU RETURN TO FRONT MENU, PRESS KEY [ N ].
***** 27640 < B GROUP > *****
CCD POSITION ADJUSTMENTS ---> [ 1 ]
ZERO POSITION AND AGC LEVEL ADJUSTMENTS ---> [ 2 ]
CCD ADJUSTMENT ---> [ 3 ]
AF C ADJUSTMENT ---> [ 4 ]
AF ADJUSTMENT ---> [ 5 ]
MAIN MENU ---> [ 6 ]
***** CCD POSITION *****
CCD POSITION SQUARE ADJUSTMENTS ---> [ 1 ]
CCD POSITION CROSS(L) ADJUSTMENTS ---> [ 2 ]
CCD POSITION CROSS(S) CHECK ---> [ 3 ]
CCD POSITION CHECK ---> [ 4 ]
CCD FOCUS ADJUSTMENT ---> [ 5 ]
B GROUP MENU ---> [ 6 ]
***** CCD POSITION SQUARE ADJUSTMENTS *****
IR -----: :-*--- (SCREW 3)
US -----: * :----- (SCREW 1)
IL -----: * :----- (SCREW 3)
OR -----: * :----- (SCREW 3)
CS -----: * :----- (SCREW 1)
OL -----: * :----- (SCREW 3)
ADJUST MORE ACCURATELY
***** CCD POSITION CROSS_L ADJUSTMENTS *****
MOUNT CCD ADJUSTING TUBE (CROSS_L) ONTO CAMERA.
SET LIGHT SOURCE TO LV 12.
SET FOCUS-MODE SAW OF CAMERA TO MF.
AFTER CONFIRMING ABOVE, PRESS KEY [ Y ].
WHEN YOU RETURN TO FRONT MENU, PRESS KEY [ N ].
***** CCD POSITION CROSS_L ADJUSTMENTS *****
US -----: * :----- (SCREW 3)
OR -----: * :----- (SCREW 1)
CS -----: * :----- (SCREW 3)
OL -----: * :----- (SCREW 1)
ADJUST WITH TOLERANCE.
***** CCD POSITION CROSS_S CHECK *****
MOUNT CCD ADJUSTING TUBE (CROSS_S) ONTO CAMERA.
SET LIGHT SOURCE TO LV 12.
SET FOCUS-MODE SAW OF CAMERA TO MF.
AFTER CONFIRMING ABOVE, PRESS KEY [ Y ].
WHEN YOU RETURN TO FRONT MENU, PRESS KEY [ N ].
***** CCD POSITION CROSS_S ADJUSTMENTS *****
IR -----: * :----- (SCREW 1)
IL -----: * :----- (SCREW 1)
ADJUST WITH TOLERANCE.
[ 3 ] AF AND RELATED ADJUSTMENTS
