14
1.2 Unpacking and packing
[Unpacking the Instrument from the case]
Set the case down gently with the lid facing upwards.
Open the latches while pressing down on the lock (safety mechanism) and open the
lid of the case.
Remove the instrument from the case.
[Packing the instrument in the case]
Make sure the telescope is fairly level and lightly tighten the telescope clamp screw.
Line up the housing marks (round yellow marks on the instrument) and tighten the
upper and lower clamp screws.
With the housing marks facing upward, set the instrument gently in the case without
forcing it.
Close the lid to the case and secure the latches.
1.3 Standard equipment
Instrument
Carrying case
BP02 battery
BC03/AC01 charger
Plumb bob
Hexagonal wrench
Rain cover
Quick Reference Guide (Basic, PTL procedures)
CD-R (Basic operation & Special Functions manual)
9
8
7
6
5
4
3
2
1
4
3
2
1
3
2
1
