11. SPECIFICATIONS
Reflectorless items are applicable to “NX”models only.
R-322NX R-323NX R-325NX R-335NX R-315NX
R-322EX R-323EX R-325EX R-335EX R-315EX R-326EX
Telescope
Image Erect
Optical aperture 45mm
EDM aperture 45mm
Reticle illumination Intensity settings: 10 steps
Auto&Power focus Yes No
Method Phase differential -
Power By main battery -
Pointer Visible la ser
Magnification 30 x
Resolving power 3”
Field of view 2.6% (1° 30’)
Minimum focus 1.0m
Auto-Focus Auto-focus / Power Focus / Manual Manual
Distance measurement
Laser Class Visible Laser: Class II (2) / Class IIIa (3R) Visible Laser:
- long range mode in Reflectorless (“NX” models only) Class II (2)
Measurement range (Good condition)
Reflectorless 1.5m -Normal range mode: 90m / long range mode 200m -
("NX" models only)
Reflector sheet 1.5m - 600m (800m)
Mini prism
1.5m - 1100m (1600m)
1P
1.5m - 3400m (4500m)
1.5m - 3000m (4000m) 1.5m - 2000m
(2800m)
3P
200m - 4500m (5600m)
200m - 4000m (5000m)
200m - 2800m
(3500m)
Accuracy
Prism ±(2+2ppm x D)mm ±(3+2ppm
Reflector Sheet x D)mm
Reflectorless ±(5+2ppm x D)mm ±(5+3ppm x D)mm -
At Auto-Atm Prism, Ref.sheet: ±(2+10ppm x D)mm ±(3+10ppm
Correction / Reflectorless: ±(5+10ppm x D)mm (“NX” models only) x D)mm
Measuring time
Repeat meas.
Normal: Prism, Ref.sheet 2.0sec. (1mm) Normal: Prism, Ref.sheet 1.2sec. (1mm)
Track: Prism, Ref.sheet 0.4 sec. (1cm) *Quick mode
Initial meas. Normal: Reflectorless 2.3sec. (1mm) Normal: Prism, Ref.sheet 2.5sec. (1mm)
(“NX”models only) *Quick mode
