7500 Series Manual
Vibration resistance 5 ... 100 Hz , 1 g, 12 m/s
2
, all axes
Impact resistance 30 g, 11 ms, all axes
Mechanical specications
Connection type electrical: 2 x 1/2 inch NPTF (open from factory)
1 x M12 opening (plugged from factory)
pneumatic: high-pressure port - 1/8 in NPTF, low-pressure port - 1/8
in NPTF
Degree of protection Type 4X, IP66
No ratings for mounting to enclosure for 7500-MTD-BX...
Material lens: Makrolon
®
GP-V polycarbonate
screws: AISI 316 (1.4401), 304, or 18-8 stainless steel
housing: A380, A356, or 6061-T6 aluminum
mounting gasket: Bisco
®
HT-800 medium cellular silicone
mounting tabs: SAE 304 stainless steel
M12 plug: 6061-T6 aluminum
Mass 710 g (1 lb 10 oz)
Dimensions 150 x 100 x 50 mm (5.9 x 4 x 2 in)
Data for application in connection
with hazardous areas
Certicate
Marking
II 3 G Ex ec nC [pzc] IIC T6...T4 Gc
II 3 D Ex tc [pzc] IIIC T60 °C ... T80 °C Dc
Directive conformity
International approvals
UL approval
cULus Class I, Division 2, Groups A, B, C, D T4 (-40 °C ≤ Ta ≤ 70 °C)
Class I, Division 2, Groups A, B, C, D T5 (-40 °C ≤ Ta ≤ 65 °C)
Class I, Division 2, Groups A, B, C, D, T6 (-40 °C ≤ Ta ≤ 50 °C)
Class II, Division 2, Groups F, G T4 (-40 °C ≤ Ta ≤ 70 °C)
Class II, Division 2, Groups F, G T5 (-40 °C ≤ Ta ≤ 65 °C)
Class II, Division 2, Groups F, G T6 (-40 °C ≤ Ta ≤ 50 °C)
IECEx approval Ex ec nC [pzc] IIC T6...T4 Gc
Ex tc [pzc] IIIC T60 °C ... T80 °C Dc
General information
Supplementary information Type Examination Certicate, Declaration of Conformity, and instruc-
tions have to be observed where applicable. For information see
www.pepperlfuchs.com.
4.1.2 Terminal Connection Data
Conductor cross section solid max. 0.2 mm²
Conductor cross section solid max. 6 mm²
Conductor cross section exible min. 0.2 mm²
Conductor cross section exible max. 4 mm²
Conductor cross section exible, with ferrule without plastic sleeve min. 0.25 mm²
Conductor cross section exible, with ferrule without plastic sleeve max. 4 mm²
Conductor cross section exible, with ferrule with plastic sleeve min. 0.25 mm²
Conductor cross section exible, with ferrule with plastic sleeve max. 4 mm²
Conductor cross section AWG min. 24
Conductor cross section AWG max. 10
