Pepperl+Fuchs 7500 Series User Manual

14
7500 Series Manual
4.1.4 Dimensions—Control Unit
1. High-pressure port 1/8-27 NPT
2. Low-pressure port 1/8-27 NPT
3. Protective earth stud, torque 12 in lb (1.35 Nm)
4.1.5 Panel Cut-Out Dimensions
149
136
97
84
4 x
R11
4 x
R4.5
48
13
34
10
7
10
20
20
19 19
4 x
M4 x .7
127
136
1/2-14
NPT
M12 x 1.5
4.5
17.5
22
84
75
44
1
2
3
137 ± 0.5
85 ± 0.5 4 x R5 ± 1
