7500 Series Manual
4.3 7500-MAN-MV-01 Manual Manifold
The 7500-MAN-MV-01 combines in one device a ball valve for purging and a needle valve for pressurizing
an enclosure. The ball valve has a handle for easy actuation. To provide security and prevent tampering, the
needle valve requires a slot-head screwdriver to set the enclosure pressure.
Note!
The 7500-MAN-MV-01 manifold can be used with 7500 series or 5500 series purge and pressurization
systems.
4.3.1 Technical Data—7500-MAN-MV-01 Manifold
General specifications
Equipment architecture max. enclosure size 450 ft
3
(12.7 m
3
)
Series 7500
Hazardous environment gas or dust
Pneumatic parameters
Protective gas supply compressed air or inert gas, 5 µm lter, free from oil
Pressure requirement 10 ... 120 psig (0.7 ... 8.2 bar)
Purge ow rate pressurization valve : Cv (ow coecient) = 0.4
purging valve : Cv (ow coecient) = 1.4
Connections inlet/outlet : 1/2 inch NPTF
Ambient conditions
Ambient temperature -40 ... 70 °C (-40 ... 158 °F)
Storage temperature -40 ... 80 °C (-40 ... 158 °F)
Mechanical specications
Degree of protection Type 4X
Material Gasket material : Bisco® HT-800 medium cellular
Mass < 1.8 kg (4 lb)
Dimensions see dimensions in chapter 4.3.2
Note
