7500 Series Manual

4.2.3 Dimensions—EPV-7500 Vents

EPV-7500-...-01/02/03

EPV-7500-PY-04

73.2

98.5

49.5

57.2

127

57.2

23.4

1 1/2 NPS thread

(3) Hex key 0.050" (included)

Exhaust port Inlet port

55.0 mm (2.15"

)

28.0 mm (1.10")

25.0 mm (1.00")

57.0 mm (2.25")

9.0 mm (0.35")

41.0 mm (1.60")

30.0 mm (1.20")

55.0 mm (2.15")

28.0 mm (1.10")

70.0 mm (2.75")

111.0 mm (4.35")
