Pepperl+Fuchs 7500 Series - Page 24

24
7500 Series Manual
EPV-7500-...-02 Vent Flow vs. Enclosure Pressure
ft
3
/m Inches of water l/m mbar
5 2.15 141 5.36
7 2.35 198 5.85
10 2.65 283 6.60
12 2.85 339 7.10
15 3.15 424 7.84
17 3.35 481 8.34
20 3.65 566 9.09
25 4.25 707 10.58
30 4.75 849 11.82
35 5.25 991 13.07
EPV-7500-...-03 Vent Flow vs. Enclosure Pressure
ft
3
/m Inches of water l/m mbar
4 2.00 113 4.98
6 2.20 169 5.48
8 2.40 226 5.98
10 2.70 283 6.72
12 3.50 339 8.71
14 4.65 396 11.58
16 6.10 453 15.18
EPV-7500-...-04 Vent Flow vs. Enclosure Pressure
ft
3
/m Inches of water l/m mbar
3 2.5 84 6.23
4 2.7 113 6.85
5 3.1 141 7.72
6 3.4 169 8.47
7 3.8 198 9.46
8 4.2 226 10.46
9 4.6 254 11.45
10 5.0 283 12.45
11 5.5 311 13.69
12 6.1 339 15.18
13 6.8 368 16.93
14 7.7 396 19.17
