7500 Series Manual
Conformity
Degree of protection EN 60529
Shock resistance EN 60068-2
Ambient conditions
Ambient temperature -40 ... 70 °C (-40 ... 158 °F) (AA and SS versions)
-20 ... 60 °C (-4 ... 140 °F) (PY versions)
Storage temperature -40 ... 80 °C (-40 ... 176 °F) (AA and SS versions)
-20 ... 60 °C (-4 ... 140 °F) (PY versions)
Relative humidity 5 ... 90 %, non-condensing
Vibration resistance 5 ... 100 Hz , 1 g, 12 m/s
2
, all axes
Impact resistance 30 g, 11 ms, all axes
Mechanical specications
Degree of protection EPV-7500....-01/02: mounting only Type 4X
EPV-7500....-03: Mounting and unit Type 4X
Material EPV-7500-AA...: body and cap 6061T6 aluminum
EPV-7500-SS...: body: 6061T6 aluminum, cap: AISI 316 (1.4401)
stainless steel
EPV-7500-PY...: body and cap: polyoxymethylene (POM)
Spark arrestor: AISI 316L (1.4404) stainless steel
Housing EPV-7500-AA... body and cap 6061T6 aluminum body and cap:
6061T6 aluminum
EPV-7500-SS... body: 6061T6 aluminum, cap: AISI 316L (1.4404)
stainless steel
EPV-7500-PY... body and cap: polyoxymethylene (POM)
Spark arrestor 304 stainless steel
Installation - any orientation to enclosure
- not gravity dependent
- internal and external mounting possible
Mass approx. 1005 g (2.2 lb)
Dimensions See dimensions in chapter 4.2.3
Mounting EPV-7500-...-01/02/03: mounting hole 1.5 in NPT knockout (50.8
mm) hole sealing nut (provided)
EPV-7500-PY-04: mounting hole 37 mm with sealing nut (provided)
Data for application in connection
with hazardous areas
Certicate
Marking ATEX: part of 18ATEX2025X
International approvals
cULus Part of the cULus classied 7500 purge system
ICEx approval Part of IECEx UL 18.0022X

Pepperl+Fuchs 7500 Series Specifications

General

Brand	Pepperl+Fuchs
Model	7500 Series
Category	Control Unit
Language	English
