7500 Series Manual
Pneumatic parameters 5500-MAN-CDUL (only 60 Hz for AC version)
Protective gas supply 5 μm ltered air or inert gas
Pressure requirement 20 psi (1.4 bar) to 120 psi (8.2 bar)
Purge ow rate (solenoid valves) Cv (ow coecient) = 1.4
Pressurization ow (needle valve) Cv (ow coecient) = 0.24
Pneumatic parameters 5500-MAN-CD01
Protective gas supply 5 μm ltered air or inert gas
Pressure requirement 20 psi (1.4 bar) to 120 psi (8.2 bar)
Purge ow rate (solenoid valves) Cv (ow coecient) = 1.4
Pressurization ow (needle valve) Cv (ow coecient) = 0.24
Pneumatic parameters 5500-MAN-EX01
Protective gas supply 5 μm ltered air or inert gas
Pressure requirement 25 psi (1.7 bar) to 115 psi (8.0 bar)
Purge ow rate (solenoid valves) Cv (ow coecient) = 1.4
Pressurization ow (needle valve) Cv (ow coecient) = 0.24
Mechanical specications
Degree of protection (connector) Type 7 and 9
Mass 2.8 lb (1250 g)
Dimensions See dimension drawings
Material
Housing Anodized aluminum
3/8 inch compression ttings AISI 316L (1.4404) stainless steel
Pressure ports 3/8 inch NPTF
Bulkhead tting AISI 316L (1.4404) stainless steel
Mounting bolts ¼-20, 316 stainless steel
Sealing washers
Pneumatic connection type Pneumatic
Input port 3/8 inch tube compression tting
Output port 3/8 inch tube compression tting
Electrical connection
5500-MAN-CD 1/2 inch NPTF thread connection with 24 inch (0.61 m) ying leads
5500-MAN-EX01 3 m cable
Warning!
Incoming power must be fused. If power is line-to-line, both must be fused. See chapter 4.1.3 for more
information.
