4 Hardware Overview
4.1 AP One Enterprise
Bottom View Top View Front View
LED Indicators
Status
RED – Access point initializing
GREEN – Access point ready
LAN 1
OFF – No device connected to Ethernet port
BLINKING – Ethernet port sending/receiving data
ON – Powered-on device connected to Ethernet port
Note that LAN 5 displays the status of the uplink connection
