SEBU8605-01 95
Maintenance Section
Engine Mounts - Inspect
Note: The cut aw
ay from section (5) in the cap allows
access to the seal.
5. Install a new fi
lter element into the breather body
(3) and orient the filter element so that position (A)
is aligned. Refer to illustration 59. Align position
(B) on t he cap
with position (A) on the filter
element.
g02415999
Illustration 61
Typical e xample
6. Install the cap (1). Rotate the cap by hand
clockwise until the cap locks into the locked
position C on the breather body.
7. Remove the container.
Check the System
g02416001
Illustration 62
Typical example
(1) Connection to breather cap for the engine
(2) Oil drain
(3) Tube assembly to atmosphere
(4) Outlet
Check the system for damage. Replace any
component that is damaged. Ensure that the outlet
(4) is clear and free from obstructions.
i02
323089
Engine Mounts - Inspect
Not
e: The engine mounts may not have been
supplied by Perkins. Refer to the OEM information
for further information on the engine mounts and the
co
rrect bolt torque.
Inspect the engine mounts for deterioration and for
co
rrect bolt torque. Engine vibration can be caused
by the following conditions:
•
I
ncorrect mounting of the engine
•
Deterioration of the engine mounts
•
Loose engine mounts
