66 SEBU8337
Maintenance Section
Engine Mounts - Inspect
g01404934
Illustration 31
Typical example
Note: The breather had an indicator (7). If the
indicator is operated then the filter element must be
replaced. The indicator will need to be reset. Remove
the plastic cover and push down the red indicator.
Install the plastic cover.
Open Breather
The open breather may be installed on some engine
applications. Ensure that breather hose assembly is
installed correctly. Ensure that the breather hose is
not damaged or restricted.
i02323089
Engine Mounts - Inspect
Note: The engine mounts may not have been
supplied by Perkins. Refer to the OEM information
for further information on the engine mounts and the
correct bolt torque.
Inspect the engine mounts for deterioration and for
correct bolt torque. Engine vibration can be caused
by the following conditions:
•
Incorrect mounting of the engine
•
Deterioration of the engine mounts
•
Loose engine mounts
Any engine moun
t that shows deterioration should
be replaced. Refer to the OEM information for the
recommended torques.
i02790188
Engine Oil Leve l - Check
Hot oil and ho
t components can cause personal
injury. Do not allow hot oil or hot components to
contact the skin.
g01165836
Illustration 32
(Y) “Low” mark. (X) “High” mark.
NOTICE
Perform this maintenance with the engine stopped.
Note: Ensure that the engine is either level or that
the engine is in the normal operating position in order
to obtain a true level indication.
Note: After the engine has been switched OFF, wait
for ten minutes in order to allow the engine oil to drain
to the oil pan before checking the oil level.
1. Maintain the oil level between the “Low” mark (Y)
and the “High” mark (X) on the engine oil dipstick.
Do not fill the crankcase above the “High” mark
(X).
