DIESEL ENGINE DATA
4006/8 Diesel, May 1998 7
For full technical data please refer to the Product Information Manual.
Type: Water-cooled, turbocharged, charge cooled, industrial diesel engine.
TYPICAL COOLING SYSTEM
*Engineonly
** Engine with heat exchanger
RANGE 4006 4008
Cycle 4 stroke
No.ofcylinders 6 8
Configuration In-Line
Bore 160 mm
Stroke 190 mm
Total swept volume 22.92 litres 30.561 litres
Compression ratio 13.6:1
Rotation Anti-clockwise looking on flywheel end
Firing order 1-5-3-6-2-4 1-4-7-6-8-5-2-3
Cylinder numbering Cylinder 1 furthest from flywheel
Valve clearances
Inlet and exhaust (cold) 0,40 mm (0.016”)
Valve dia (mm)
Inlet and exhaust
48 (early engine)
52 (later and uprate engines)
Valve setting See Page 43
Valve timing See Workshop Manual Section U
Injection timing See Engine Number plate
Piston speeds Engine r/min
1000
1200
1500
1800
m/s (ft/min)
6.33 (1247)
7.60 (1496)
9.50 (1870)
11.40 (2244)
Approved coolants See Page 17
Water capacity (block only) 36 litres (8 gal) 48 litres (10.5 gal)
Total water capacity Litres Gals Spec Litres Gals Spec.
Engine with tropical radiator 106 23.3 TG 135 29.7 TAG
110 24.2 TAG1 145 31.9 TAG1
110 24.2 TAG2 145 31.9 TAG2
125 27.5 TAG3 48 10.6 TWG2*
106 23.3 TWG
130 28.6 TWG3
46 10.1 TEG**
Engine shut down temperature 96°C
Max water temperature into engine
To be determined from heat dissipated & water flow
through each particular engine model
Thermostat opening temperature 71°C
System pressure 0.5 to 0.7 bar
