TORQUE SETTINGS
4006/8 Diesel, May 1998 13
LUBRICATING OIL PUMP lbf.ft Nm
Bolts, pump housing to gearcase plate M10 35 50
Thin nut, gear to drive shaft M24 175 237
CAMSHAFT GROUP
Camshaft gear bolt M12 110 150
Camshaft thrust plate bolt M10 35 50
Camshaft follower housing bolt M10 35 50
Idler gear hub bolts M10 35 50
WATER PUMP
Water pump gear nut M24 170 230
Water header to oil cooler bolts M10 35 50
Water header to gearcase bolts M10 35 50
Raw water pump gear securing nut, dry thread M35 18 244
ENGINE FEET
Engine feet to base frame bolts M20 350 475
Engine feet to cushion feet bolts M16 160 215
Engine feet to gearcase and suspension plate bolt M10 35 50
GOVERNOR
Control shaft mounting plate bolt M10 35 50
FAN DRIVE
Fan driven pulley taper lock bush screws
1
/
2
" BSW 35 50
Fan driven pulley taper lock bush screws
5
/
8
" BSW 65 90
ALTERNATOR
Drive pulley taper lock bush nuts
3
/
8
" BSW 15 20
FUEL PUMP/INJECTORS
Injector capscrew clamp to cylinder head, early
engines M10 50 70
Injector capscrew clamp to cylinder head, later
engines M12 70 95
Injector nozzle nut to holder M27 150 203
Fuel pump control linkage screw 2BA 6 8
Unit injector control lever capscrews M5 6 8
FLEXIBLE COUPLING (HOLSET)
Flexible coupling cover screw M12 or
1
/
2
" UNC 90 129
Coupling driving flange screws (coupling size 2.15) M12 or
1
/
2
" UNC 90 129
