Perry Electric TE541 - SET OFF, Anti-Freeze Protection (Winter) or Thermal Protection (Summer)

10.5 - SET OFF, Anti-freeze protection (Winter) or Thermal protection (Summer)
Example: Default value 5.0C Set OFF
in modeWINTER
Select
with the buttons
•From normal operation of the thermostat, access the menus by holding down the button as described in Chap. 9, the screenMode SEt OFF
appears, confirm with .OK
Example: Set OFF deactivated (default)
in modeSUMMER
To DEACTIVATE Tset OFF (antifreeze), go below +4.0 °C
= Antifreeze OFF temperature deactivated
Each press of results in a change of 0.1 degrees;or
.tress and hold to scroll quickly through the values
Antifreeze OFF protection range: +4 °C at t2
Thermal protection OFF range: +37.7 °C at t2
•Select the to be changed for WINTER mode (antifreeze) or SUMMER mode (thermal protection) using the buttonsSET OFF .
•Confirm with the button, OFF flashesOK .
•With the buttons set the desired antifreeze or thermal protection T Set OFF temperature. Press to confirm.OK
In this case, the system will be
exposed to possible frost damage.
•Press the button and then to select another menu item or press the button twice to exit the menus and return to normal operationMode Mode .
Example: TSET OFF (antifreeze) modified
Example: TSET OFF (thermal protection) modified
19
If the OFF level of antifreeze or thermal protection is deactivated and the user sets a minimum lock for Winter or a maximum lock for Summer (see par.10.3), the
OFF level is automatically re-enabled and automatically sets the minimum lock value for Winter or maximum lock value for Summer; it will be prevented
for the user to attempt to disable the protection level again() .OFF
