PEUGEOT MOTOR ENGINE - To Remove the Clutch Pulley Assembly; To Remove the Governor - Type 3

DISASSEMBLY
Page: 9
Reproduction or translation, even partial, forbidden without the written consent of Peugeot Motocycles
To remove the governor - type 3
Lock the bobweight plate (1) with the adjustable pin
wrench P/N 755586
- Remove the nut (2) from the end of the crank
assembly
- Remove the governor assembly (1)
To remove the clutch pulley assembly
- Remove the panels (1)
- Remove the kickstart lever (2)
- Remove the chain guard (3) and the RH footrest (4)
- Remove the quick-link and the chain (5)
- Remove the circlip (6), the sprocket (7) and its
plastic washer
