Setting up
9 - 3
Place an empty bobbin 1 onto bobbin spindle 2.
Thread the bobbin in accordance with Fig. 9-04 and wind it clockwise around the
bobbin 1 a few times.
Engage on the bobbin winder by pressing bobbin winder shaft 2 and lever 3 at the same
time.
The bobbin fills up during sewing.
The tension of the thread on bobbin 1 is adjusted with knurled screw 4.
The bobbin winder stops automatically when there is enough thread on bobbin 1.
If the thread is wound unevenly:
Loosen nut 5.
Turn the thread guide 6 accordingly.
Tighten nut 5.
Fig. 9 - 04
6
4
9.04 Winding the bobbin thread, adjusting the thread tension
-
+
5
3
1
2
