Pfaff 1244

Adjustment
11 - 6
11.04.05 Centering the needle in the needle hole (for the PFAFF 244, 1243 and 1244)
Requirement
With the stitch length set at „0“, the needle must enter the needle hole exactly in the middle.
Fig. 11 - 05
● Loosen screws 1, 2 and 3.
● Position the needle directly above the feed dog by turning the balance wheel.
● Position needle bar frame 4 in accordance with the requirement.
● Tighten screws 1, 2 and 3.
2
3
4
1
