Pfaff 1571 - Needle Position Crosswise to Sewing Direction (on the PFAFF 1591 and 1593)

Adjustment
15
15.04.08 Needle position crosswise to sewing direction (on the PFAFF 1591 and 1593)
Requirement
As seen crosswise to the sewing direction, the needle must penetrate in the centre of the
needle hole.
 Adjust feed wheel post 1 (screws 2, 3 and 4) according to the requirement.
2
3
1
Fig. 15 - 08
3
4
4
4
2
2
1
4
4
4
