Pfaff 1571 Adjustment Manual

Adjustment
53
15.07.05 Parameter list for control DAC Compact
Group Parameter Description Setting range Set value 1574 Set value 1571; 1591;1593
100
101 Display main processor software version 0461/xxx
102 Show software version of the bootloader 0458/xxx
103 Display sewing drive component software version 0427/xxx
104 Display control panel software version VxxxHyyy
196 Display hardware ID of the controller
197 Show serial number of the controller 600-xxxx-xxxxxx
198 Show serial number
199 Display product number
1400
1402
Roller presser lowering speed
0 = slow, 1 = quick
0 - 1 0 0
1460 Holdoff time roller presser lift 0,001s - 1,500s 0,050s 0,050s
1461 Lower start delay after roller presser 0,001s - 1,500s 0,050s 0,050s
1462
Set roller presser lift
Must be increased for high foot pressure
0,001s - 0,200s 0,080s 0,080s
1480 Roller presser magnet pulse 10% - 50% 35% 35%
1500
1501
Placed stitch , 0 = OFF, 1 = ON
0 - 1 0 0
1520 Placed stitch position 0° - 359° 20° 20°
1700
1703
Open thread tension on stop and roller presser
lift
0 = OFF, 1 = ON
0 - 1 1 1
1704
Open thread tension after trimming and roller presser
lift
0 = OFF, 1 = ON
0 - 1 1 1
1720 Thread tension ventilation position 0° - 359° 290°
300°(1571)
300°(1591)
290°(1593)
1760 Time thread tension ventilation before timing 0,001s - 1,500s 0,100s 0,100s
1780 Thread tension magnet timing 10% - 50% 35% 35%
1800
1840 Start backtack speed 100 - 1500 700 700
1841 End backtack speed 100 - 1500 700 700
2000
2010 Stitch length at the touch of a button (parameter stitch) 0,8 - 7,0mm 4,0mm 4,0mm
2011 Soft starting stitches 0 - 15 0 0
2040 Soft start speed 100 - 3500 1500 1500
2041 Minimum speed 100 - 300 180 180
2042 Maximum speed 100 - 3500 3500 3500
2200
2201
Bobbin thread monitor (0 = OFF, 1 = Counter)
0 - 1 0 0
2210 Bobbin thread counter 0 - 99999 12000 12000
