Adjustment
19
15
.04.1
1
Height of the f
eed wheel
(on the PF
AFF 1
591 and 1
593)
Requirement
The f
eed wheel should protrude from the needle plate b
y tooth height (approx.
0
.
8
mm)
Swing out the roller presser
.
Loosen scre
ws
1
.
Adjust eccentric
3
(f
astening screw accessible through hole
2
) according to the require-
ment.
Tighten screws
1
.
2
3
1
Fig. 15 - 1
1
0,8 mm
18
20
