Adjustment

15.06.08 Linkage rod (only on the PFAFF 1574)

Requirement

The driving levers 1 should be parallel when the thread trimmer is the neutral position.

 Adjust the driving levers 1 (screws 2) according to the requirement.

Fig. 15 - 37
