Adjustment
2 - 33
2.34 Pressure of the vibrating- and lifting pressers
Requirement
Even at the highest sewing speed the material must still be fed reliably, but there must not
be any pressure marks on the material.
● Set regulating screw 1 for the pressure of the vibrating presser flush with the top surface
of the housing.
● Turn regulating screw 2 (nut 3) for the pressure of the lifting presser so that its shoulder
is at a distance of about 12 mm from the machine housing.
It may be necessary to increase (+) or decrease (-) the pressure of the vibrating-
or lifting presser.
Fig. 2 - 32
12 mm
3
2
1
+
+
-
-
