2 - 18
Adjustment
2
1
● Turn eccentric pin 1 (screw 2) according to Requirement.
Fig. 2 - 17
2.19 Position of lifting presser
Requirement
When the bottom feed dog is at t.d.c. the lifting presser must be parallel with the drop
feed dog.
