Pfaff 487 Service Manual

2 - 34
Adjustment
2.35 Stitch length limitation
● Loosen or, depending on the amount of limitation, take out screw 1 (accessible through
the fitting window).
● Set feed regulator lever 2 to the required maximum stitch length.
● Place limitation stop 3 onto regulator lever 3 and secure it with screw 1 in the top or
bottom hole (depending on the amount of limitation).
Fig. 2 - 33
1
2
3
