Pfisterer MV-CONNEX 3 - Configuration Components

16 www.psterer.com
6.4 Conguration
Contact ring
Tension cone
Thrust piece
Insulating part
Capacitive voltage tap (optional)
Screws M8
x
45
Gasket
Bell ange
Capacitive voltage tap (optional)
Heat-shrink tubing
Technical Data / Conguration
