With MV-CONNEX you have a modern cable connector system. The socket

is already built into the switchgear. In the following instructions, the instal-

lation of the pluggable connector is described and illustrated step by step.

Please observe the sequence of steps during the installation. Installation

should be carried out by tters who have been trained by PFISTERER.

2 General Information

2.1 Information regarding the installation instructions

These assembly instructions describe the safe and proper use of the pro-

duct described. The specied warnings and instructions, and the appli-

cable local accident prevention regulations must be observed together

with general safety regulations.

Before starting work on the product, read the installation instructions all

the way through, particularly the chapter on safety and specic safety pre-

cautions. It is vital that what is read is understood. The installation instruc-

tions are a part of the product. It must be kept available and accessible in

the immediate vicinity of the product (e.g. control room, switch room) at

all times.

2.2 Contents of the installation instructions

Any person who is tasked to perform work on or with the product must

have read and understood the installation instructions before commenci-

ng the work. This is the case even if the person has already worked with this

or a similar product or has been trained by the manufacturer. Knowing the

contents of the installation instructions is one of the requirements for the

protection of personnel from hazards and the avoidance of mistakes, and

to operate the product safely and in a trouble-free manner. The operator is

recommend to ensure that sta can demonstrate that they have taken note

of the contents of these installation instructions.

General Information

2.3 Additional installation instructions

Depending on the scope of delivery (e.g. special versions or additional op-

tions that may have been ordered) these instructions may be supplemen-

ted by additional installation instructions, which must be observed and

applied in the same way.

Drawings not to scale - for information only Size 3 | 3-S / Standard instructions wire screen / No. 040 371 001 (2014-05-08) i-01
