Pfisterer MV-CONNEX 3 - Unplugging and Plugging In; Unplugging Procedure

44 www.psterer.com
Drawings not to scale - for information only Size 3 | 3-S / Standard instructions wire screen / No. 040 371 001 (2014-05-08) i-01
12 Unplugging / Plugging in
12.1 Unplugging
Loosen cable screen, test lead (if present) and remove the earthing of
the bell ange.
1 1
Loosen the mounting screws and carefully unplug.
2 1
Optional removal device
Unplugging/ Plugging In
XII
