Phase AxN series - Page 56

54
User Connector U2
Pin
Name
Function
Signal Description
13
GND
Analog reference ground
Analog signals reference
14
R1P
Differential analog input
+/-10V, Zin=10KΩ
15
R1N
Differential analog input
+/-10V, Zin=10KΩ
16
AO1
Programmable analog output
+/-10V f.s., 30 mA
17
GND
Analog reference ground
Analog signals reference
18
DI4
Programmable digital input
6.6 kΩ to ground, 20-30 V
19
DI5
Programmable digital input
6.6 kΩ to ground, 20-30 V
20
DI6
Programmable digital input
6.6 kΩ to ground, 20-30 V
21
DI7
Programmable digital input
6.6 kΩ to ground, 20-30 V
22
DO2
Programmable digital output
PNP open collector, 24 V, 100mA max
23
DO3
Programmable digital output
PNP open collector, 24 V, 100mA max
24
0V
Auxiliary supply negative
Digital signal reference
Notes:
1. Pin 4, 13 and 17 are the same analog reference ground;
2. Pin 1 and 2, 14 and 15 are two pairs of differential analog input. If not using differential signal,
connect pin 1, 2, 4 and 15 separately to analog reference ground (pin 4, 13 and 17), you will
have 4 channels of programmable analog input;
3. Pin 12 and 24 are the same digital signal reference.
