56
Pin Assignment
Insulated User Connector U3
Pin
Name
Function
Signal Description
1
IS_AO0P
Programmable analog output
Insulated analog output channel No.0:
±10V f.s., 30 mA
2
IS_AO0G
Analog reference ground
Insulated analog output channel No.0:
Insulated reference ground
3
IS_AO1P
Programmable analog output
Insulated analog output channel No.1:
±10V f.s., 30 mA
4
IS_AO1G
Analog reference ground
Insulated analog output channel No.1:
Insulated reference ground
5
IS_AI0G
Analog reference ground
Insulated analog input channel No.0:
Insulated reference ground
6
IS_AI0P
Programmable analog input
Insulated analog input channel No.0: ±10V
7
IS_AI1G
Analog reference ground
Insulated analog input channel No.1:
Insulated reference ground
8
IS_AI1P
Programmable analog input
Insulated analog input channel No.1: ±10V
9
IS_AI2G
Analog reference ground
Insulated analog input channel No.2:
Insulated reference ground
10
IS_AI2P
Programmable analog input
Insulated analog input channel No.2: ±10V
11
IS_DO0P
Programmable digital output
Insulated digital output channel No.0:
On/Off switch, 9V ~ 28Vdc/2A
12
IS_DO0N
Programmable digital output
Insulated User Connector U4
Pin
Name
Function
Signal Description
13
DI_COM
Digital reference ground
Insulated reference ground for digital input
14
IS_DO1P
Programmable digital output
Insulated digital output channel No.1:
On/Off switch, 9V ~ 28Vdc/2A
15
IS_DO1N
Programmable digital output
16
IS_DI0
Programmable digital input
5mA, 24Vdc max
17
IS_DI1
Programmable digital input
5mA, 24Vdc max
18
IS_DI2
Programmable digital input
5mA, 24Vdc max
19
IS_DI3
Programmable digital input
5mA, 24Vdc max
20
IS_DI4
Programmable digital input
5mA, 24Vdc max
21
IS_DI5
Programmable digital input
5mA, 24Vdc max
22
IS_DI6
Programmable digital input
5mA, 24Vdc max
23
IS_DI7
Programmable digital input
5mA, 24Vdc max
24
DI_COM
Digital reference ground
Insulated reference ground for digital input
Notes: Pin 13 and 24 are the same digital reference ground.
