ROUTINE MAINTENANCE
Replacement of glow starter
The glow starter is located above the remote alarm terminal inside the front cover. [Fig. 1]
1. Turn off the power switch and then disconnect the power
supply plug.
Before turning off the power switch, turn off the light
switch if the light switch is on.
2. Open the front cover. [page 13]
3. Remove the drip-proof cover and the glow starter.
4. Install a new glow starter. (glow starter; FG-1P)
5. Replace the drip-proof cover.
6. Close the front cover.
7. Connect the power supply plug to the outlet and turn on the power switch.
8. Turn on the light switch to check the fluorescent lamp is on.
Fig.1
Glow starter
(inside the drip-proof cover)
