VARIOUS SETTING (MENU/Tools)
Set of log interval (Tools/Log Interval)
This product can change the set point of the log interval (Log Interval) between 2 minutes and 30 minutes.
(Factory setting is 15 minutes.) It can be recorded for about 5 weeks when the log interval is 15
minutes.
Table 12. The log interval set-up steps (When a log interval is changed from 15 minutes to 10
minutes.)
Description of operation Key operated Indication after operation
1 -----
Top screen is displayed.
2 Press the MENU button. MENU
The menu window is indicated. And the
“set” is highlighted.
3
Press the shift key (downward),
highlight the “Tools” menu window,
and press the ENTER key.
▼
ENTER
Select Tools screen is indicated.
4
Press the shift key (downward),
highlight the Date Time by pressing
ENTER keys.
▼
ENTER
The Date Time screen is indicated.
5
Select Log Interval by pressing the
shift key (downward).
▼
The numerical value of the Log Interval is
highlighted.
6
Press the figure input key in the 1, 0
order.
Log Interval is changed from 15 to 10.
7 Press the MENU key. MENU
The menu window is indicated. And the
“OK” is highlighted.
8 Press the ENTER key. ENTER
Log Interval is memorized, and the Select
Tools screen is indicated.
9 Press the MENU key. MENU
The menu window is indicated. And the “OK”
is highlighted.
10
Press the shift key (downward) to
highlight “Cancel” in the menu
window, and press the ENTER key.
▼
ENTER
Top screen is displayed.
